Handheld Mobile Computer Handheld Computer With Barcode Scanner Nfc
Handheld Terminal BH85
4 inch professional handheld logistic pda with keyboard,we use
Corning Gorilla tempered glass touch panel and double injection
mould housing to make it MIL-STD-810G standard and shockproof with
5.0M front camera and back 8.0M,4100mah big battery to make it work
for whole day,Quad core CPU and Android 7.0 OS,hand strap for
better carry,Now our customers they mainly use the devices in
logistic and retail etc
| Product Outlook |
| Type | Details | Standard Configuration |
| Product Form | Type | Rugged handheld computer |
| Dimension | 164*71*23 |
| Weight | Device unit: 400g ,Unit with giftbox and standard
accessories:550g,Docking:200g |
| Device Color | fully black |
| LCD | Screen Size | 4.0 inch |
| Resolution | 480*800 |
| Brightness | 300Nit |
| TP | Touch Panel | 5points Capacitive,Corning gorrila glass |
| Camera | Front | Front5.0MP |
| Rear | Rear 8.0MP,with flash and auto-focus |
| Speaker | Built-in | Embedded 8Ω/0.7W speaker x 1 |
| Mic | Built-in | Sensitivity:-42db, output resistance2.2kΩ |
| Battery | type | Li_polyment,battery loadable |
| Capacity | 3.8V/4100mAh |
| Endurance | 12hrs(default50%volumn,default 200lumens brightness,play1080P
video) |
| System Hardware Configuration |
| Type | Details | Descriptions |
| CPU | Type | 4core |
| Speed | 1.3GHz |
| GPU | Type | ARM MaliT720-MP3 450MHz |
| RAM | DDR3L | 2GB/ LPDDR3 |
| ROM | Emmc | 16GB |
| Network Connections |
| Type | Details | Descriptions |
| WIFI | WIFI | WIFI 802.11(a/b/g/n) Frequency 2.4G+5.8G dual band WIFI, |
| Bluetooth | Built-in | BT4.0(BLE) class1transmission |
| 3G/4G | Built-in | CMCC 5M:
LTE 1/2/3/4/7/17/20/38/39/40/41
WCDMA 1/2/5/8
TD-SCDMA 34/39
GSM 2/3/5/8 |
| GPS | Built-in | support:GPS;Capture sensitivity::-160 dBm；Cool Start Time:<60
seconds,Hot start time:<28seconds,frequency::0.25 Hz … 10 MHz
(configurable) |
| NFC | Option | ISO/IEC 14443A, ISO/IEC 14443B PCD 106 kbit/s to 848 kbit/s
ISO/IEC 14443A, ISO/IEC 14443B PICC 106 kbit/s to 424 kbit/s
MIFARE reader encryption mechanism (MIFARE 1K/4K)
Reading NFC Forum tags (MIFARE Ultralight, Jewel, FeliCa open
tag,ISO/IEC 14443-4)
Reading DESFire card
ISO/IEC 15693/ICODE reader
NFC-IP1 and NFC-IP2 protocols (ISO/IEC 18092 /ECMA 340 and
ISO/IEC 21481/ECMA 352) 106 kbit/s to 424 kbit/s
B’ and MIFARE card emulation
|
| 1D barcode scanner | Option | Honeywell N4313 |
| 2D barcode scanner | Option | SE4710 or 2100 |
| Interface Configuration |
| Type | Details | Descriptions |
| TF slot | Extensive External Memory | support SDHC/SDXC x1 max:64G |
| SIM slot | SIM card | SIMx1 |
| PSAM slot | PSAM card | PSAM*1 |
| Type c interface | data transmission | Type C usb 2.0*1 OTG |
| HOME key | home | HOME*1 |
| Menu Key | Menu | MENU*1, |
| Back Key | Back | BACK*1, |
| number key | number | numbers*10 |
| barcode | barcode | barcode *3 |
| D.C PIN | docking charger | charging function x1 |
| Power on | press key | power key x1 |
| Volume + - | press key | Volume + - x1 |
| Standard Accessories |
| Type | Details | Description |
| USB cable | USB cable | Type c USB cable |
| Power Adaptor | Standard | AC100V ~ 240V,50Hz/60Hz output DC 5V/2A USA Standard CE approval |
| Docking station | Optional | charing |
| bag | optional | holder |
| Software Configuration |
| Type | Details | Description |
| Operation System | OS version | Andriod 7.0 |
| Reliability |
| Type | Details | Descriptions |
| Product Reliability | Drop Height | 1.2m composite wood floors, in operation status |
| Operate Temperature | ‘-10 °C to 50 °C |
| Store Temperature | ’-30 °C to 70 °C |
| Humidity | Humidity: 95% Non-Condensing |
FAQ
Qustions 1 :Which kind of Barcode scanner modules?
BH85 we choose Moto 4710 module for 1D/2D
Question 2: What kind of services do you support ?
1.We provide you Free SDK and Technical Support
2.We also provide ODM/OEM Customization Services based to your
demands.
3.We support 12 months Warranty for all the device and 6 months for
the batteries. Extension warranty, it costs 10% at the first year,
and 20% for the second year.
Question 3: Are you a manufacturer of rugged devices?
Yes, we have our own R&D team including software and hardware
engineers and assembly factory,mainly producing industrial PDA and
rugged tablet ,.
Question 3: How long is the delivery time?
The delivery time of rugged android tablet goods is different from
quantities:
for samples, It's about 3-5 working days;
If 100~500 pcs, it's about 10--20 working days;
If More than 500 pcs, It's about 20-30 working days.
Question 4: Who are your customers?
1. Our products have been sold to worldwide,especially market in
South/North America, Europe, Asia, Africa Mid-east, etc.
2.The market share is increasing quickly every year and we get more
and more positive feedbacks from our customers
Bright Alliance based on the continuous development of industrial
terminal technology and independently develops the industrial
rugged devices, including Handheld computer and rugged tablet,And a
variety of accessories can be selected to meet customers' demand
for industry, aviation, aerospace, vehicle-mounted, police,
education, exploration, fishing animal husbandry, finance and other
industries.now our customers are mainly system integrator and
solution provider,create new service and usages to the end users.
